Washer Nozzles

The windscreen washer nozzle is located on the A/C air intake grille panel. The angle of windscreen washer nozzle is configured during assembly. Do not make any adjustment to its direction. To adjust the windscreen washer nozzle, you can insert a small flat-bladed screwdriver in the gap (area as indicated by the arrow) between the housing (1) and the nozzle (2) and turn upward or downward slightly to achieve an appropriate washer jet angle. Operate the washer to spray water periodically to check if the washer nozzle is clean and aimed in the correct direction. If the nozzle is obstructed, insert a needle or thin metal wire into the hole to remove the obstruction.
